SwingMan 25D

SwingMan 25D

SwingMan 25D© Fast Facts

  • SwingAway Platen.
  • Digital Time and Temperature Control.
  • Items up to 1 1/8" Thick
  • Full Pressure Adjustment
  • Heavy duty even heating
  • Lifetime warranty on heating element.
  • Digital timer reads in both minutes and seconds
  • Repeatable pressure settings
  • self-leveling lower

SwingMan 25D© Specs
  • 20" x 25" Platen (50.8 x 63.5cm)
  • Box Size 34" x 33" x 24" (87 x 84 x 61cm)
  • 17.7 Amps 4250 Watts
  • Shipping Weight 135 lbs + Crating

SwingMan 25D© Overview

The 20"x25" (swingaway) SwingMan 25D single is designed for pressing larger tile murals, 3XL-4XL shirts, signage, reflective stripping and much more!

Apply an astounding 1200 lbs of downward force and transfer images in excess of 19"x24" in one pressing. The Swingman 25D features a 20"x25" (surface area) heat platen with a swing-away design and the standard lifetime warranty on its heating element. Similar to the Swingman 20D; features include digital timer reading in both minutes and seconds. Digital temperature settings with range up to 450°F and full range repeatable pressure adjustments for items up to 1-3/4" thick. The press has a sleek design and over-center lever providing easy lock down.

No longer are you limited to 16"x20" images or multiple pressings on oversized garments, press a full 23 inches, perfect for applying reflective stripping or names to 3XL and 4XL shirts in one pressing.

Press a complete 18"x24" ceramic tile mural in one pressing saving you time and money. Uneven pressure is eliminated with the self-leveling design of the lower platens.

The increased size of the platen now opens up more opportunities for cut and sew manufacturers, signage and sublimation applications that cover a multitude of substrates. Not only can you press larger items but the increased size also allows you to press multiple smaller items in one press perfect for increased production!
